The resource requirements for the host PC depend on the connection
between the host PC and the expansion box:
Connection via DS815, DS817, DS819, or DS821 Link Board The
Link Boards require the following resources in the host PC:
Resources in the host PC
Required
Address Bytes
Default I/O Base
Address
Required
Memory
IRQ
10H Plug & Play None 1 n ISA for DS815
n PCI for DS817
n PCI Express for DS819/DS821
The DS819 and DS821 Link Boards are supported by the dSPACE
software since dSPACE Release 5.2.
Connection via Ethernet The boards installed in the expansion box
require no resources in the host PC.
The slot CPUs installed in the expansion box as provided by
dSPACE do not conflict with the default I/O base addresses
of dSPACE boards.
Connection of MicroAutoBox to the Host PC
MicroAutoBox can be connected to the host PC via the Link Boards
DS815, DS817, DS819 or DS821. The following resources are
required in the host PC:
Resources in the host PC
Required
Address Bytes
Default I/O Base
Address
Required
Memory
IRQ
10H Plug & Play None 1 n ISA for DS815
n PCI for DS817
n PCI Express for
DS819/DS821
s
Resource Requirements of dSPACE Boards
t
DS1103 Hardware Installation and Configuration November 2014
33
