Connector Pinouts and LEDs
This chapter provides hardware-related, reference information on the
components of the DS1103 and its optional accessories, the CP1103
Connector Panel and the CLP1103 Connector/LED Combi Panel:
Objective
Information in this section
DS1103 Components
Contains an illustration of the board, and the pin assignments of the
different board connectors.
104
CP1103/CLP1103 Components
Shows the front view of the connector panel and the pin assignments of
the connectors equipped on the panel.
127
Information in other sections
Mapping of I/O Signals
Various connector pins can be assigned to RTI blocks and RTLib functions.
139
Where to go from here
DS1103 Hardware Installation and Configuration November 2014
103
