Incremental Encoder Interface
The DS1103 provides a digital incremental encoder interface with
input channels for seven incremental encoders. The pins which make
up the inputs are called:
n PHI0(1) … PHI0(7), PHI0(1) … PHI0(7)
n PHI90(1) … PHI90(7), PHI90(1) … PHI90(7)
n IDX(1) … IDX(7), IDX(1) … IDX(7)
The incremental encoder interface supports:
n Six digital encoder channels (Ch1 …Ch6) providing single-ended
TTL and differential RS422 signals (programmable by software).
n One analog encoder channel (Ch7) providing 1 V
pp
or 11 μA
pp
differential signals (programmable by software).
Ch6 and Ch7 are based on the TC3005H Tacho Controller.
For detailed information on the TC3005H (for example the
data sheet) contact dSPACE.
Objective
Information in this section
Hardware details
Digital Encoder Interface: I/O Circuit and
Electrical Characteristics
178
Analog Encoder Interface: I/O Circuit and
Electrical Characteristics
179
Recognizing Encoder Index Interrupts 181
Connecting Encoders 182
Supplying Power to Encoders 186
Information in other sections
Feature description
Incremental Encoder Interface ( DS1103
Features)
Where to go from here
s
Incremental Encoder Interface
t
DS1103 Hardware Installation and Configuration November 2014
177
t
