Mapping of I/O Signals
Various connector pins can be assigned to RTI blocks and RTLib
functions.
Objective
Information in this section
Signal Mapping to I/O Pins
Shows the assignment of RTI blocks and RTLib functions to single
connector pins.
139
Conflicting I/O Features
Shows the I/O features on the DS1103 which conflict with other I/O
features.
152
Signal Mapping to I/O Pins
The following table lists the I/O signals of the DS1103 by function
groups, their electrical specifications, and the mapping of these
signals to RTI blocks and RTLib functions.
The table also provides the mapping of the I/O signals to the I/O pins
on the DS1103, on the Sub‑D connectors, and on the
CP1103/CLP1103 connector panels.
Objective
Some I/O features of the DS1103 conflict with other I/O features. In
the table below, these signals are marked with an asterisk “*“.
For an overview, see Conflicting I/O Features on page 152.
Conflicting I/O features
Where to go from here
