dSPACE DS1103 User Manual

Parameter Specifications
Space needed for 19” rack mount Height 3 U; width 16.8“
Weight Approx. 3.8 kg (8.4 lbs); incl. enclosure and shielded
ribbon cables
CLP1103 Data Sheet
The following table shows the data sheet of the CLP1103
Connector/LED Combi Panel.
Technical data
Parameter Specifications
Power consumption 5 V; max. 750 mA (via DS1103 board)
Grounding The enclosure and the front panel are not grounded.
Cable length 2 m (6.6 ft) standard
Physical size (with desktop enclosure) (length
x depth x height)
647 x 142.5 x 70 mm
(25.47 x 5.61 x 2.75 in)
Space needed for 19” rack mount Height 3 U; width 16.8“ + height 3 U; width 8.4“
(2 slots needed)
Weight Approx. 4.3 kg (9.5 lbs); incl. enclosure and shielded
ribbon cables
s
DS1103 and CP1103/CLP1103
t
DS1103 Hardware Installation and Configuration November 2014
225
t

dSPACE DS1103 Specifications

General

Brand	dSPACE
Model	DS1103
Category	Controller
Language	English
