The following diagram shows the physical dimensions of the
Tandem‑AutoBox with heater that diverge from the one without
heater.
Tandem‑AutoBox with
heater
485 mm (19.1 in.)
525 mm (20.7 in.)
Not to scale
Power Input Connector
Each power supply unit provides a power input connector. It is a 7-
pin, male connector with two high‑current pins. It is adapted from a
15‑pin Sub-D connector.
Objective
s
dSPACE Expansion Boxes
t
DS1103 Hardware Installation and Configuration November 2014
293
