Serial Interface
The DS1103 contains a Universal Asynchronous Receiver and
Transmitter (UART) to perform communication with external devices.
The DS1103 allows you to use the serial interface in the RS232 or
RS422 mode.
Signal names are dependent on the mode used. They are in
accordance with the published specifications.
Objective
Information in this section
Hardware details
I/O Circuit and Electrical Characteristics 188
Connecting RS232 Devices 189
Connecting RS422 Devices 191
Information in other sections
Feature description
Serial Interface ( DS1103 Features)
The board contains a universal asynchronous receiver and transmitter
(UART) to communicate with external devices.
Where to go from here
s
Serial Interface
t
DS1103 Hardware Installation and Configuration November 2014
187
