DS1103 Data Sheet 220
CP1103 Data Sheet 224
CLP1103 Data Sheet 225
DS1103 Data Sheet
The following table shows the data sheet of the DS1103 PPC
Controller Board for different board revisions.
Technical data
Parameter Specification
As of Board Revision
DS1103-09
Up to Board Revision
DS1103-07
Processor PowerPC Type PPC750GX PPC604e
CPU clock 1 GHz 400 MHz
Cache n 2 x 32 KB level 1 (L1)
(on‑chip)
n 1 MB level 2 (L2)
2 x 32 KB level 1 (L1)
(on‑chip)
Bus frequency 133 MHz 66 MHz
Temperatur sensor Reads actual temperature at the PPC
Memory Local memory
(as program memory for
application)
32 MB SDRAM 2 MB SRAM
Global memory
(for data storage and
data exchange with
host)
96 MB SDRAM 128 MB SDRAM
Where to go from here
s
Data Sheets
t
220
s
DS1103 Hardware Installation and Configuration November 2014

dSPACE DS1103 Specifications

General

Brand	dSPACE
Model	DS1103
Category	Controller
Language	English
