Using dSPACE CardSafe
To hold the DS815 or DS821 firmly in a notebook slot, you can use
the dSPACE CardSafe. The dSPACE CardSafe protects the inserted
dSPACE link boards, cables, or connectors against unwanted removal
from the notebook and against damage.
Objective
Information in this section
Introduction to dSPACE CardSafe 65
How to Mount dSPACE CardSafe 68
How to Remove dSPACE CardSafe for
Transportation
72
How to Remove dSPACE CardSafe Completely 72
Introduction to dSPACE CardSafe
The dSPACE CardSafe consists of a base plate and a card holder. The
base plate is fixed to the underside of the notebook and does not
have to be removed for transportation. The card holder must be
plugged into the base plate. The height of the clamp plates can be
adapted to the notebook slot via bolt spacers.
Overview
Where to go from here
s
Using dSPACE CardSafe
t
DS1103 Hardware Installation and Configuration November 2014
65
