Parameter Specification
Reset switch (up to revision 3.0) n The switch has no function.
n The lamp in the switch lights up when the
expansion box power supply provides +12 V.
n Approx. 10,000 h life span of the lamp
Grounding Circuit ground is connected to the chassis and
through that to the power system’s protective
ground.
Physical size Refer to PX10 Dimension Drawings
on page 256
Rack-mount
version: space
needed in a
19" rack
Height 4 U (HE)
Width 13.5"
Weight
(without
boards)
Desktop version n Up to revision 3.4: 10.8 kg (22 lbs)
n As of revision 3.5: 11.1 kg (24.5 lbs)
Rack-mount version n Up to revision 3.4:12.8 kg (26.5 lbs) with
19" front plate and mounting plate
n As of revision 3.5: 13.4 kg (29.5 lbs) with
19" front plate and mounting plate
Ambient temperature (Ta)
1)
0 … 50 °C (32 … 122 °F)
Humidity 20 … 90 %, non-condensing
1)
The ambient temperature specified for boards installed inside the box (for example, the DS1006) can limit the stated
temperature range
As of revision 1.3, the revision number is labeled on the chassis and
the PX10 is prepared for inserting max. one DS1006 Processor Board.
For more details on the different revisions, refer to
http://www.dspace.de/goto?pxboxvers.
PX10: Ensuring Correct Operating Temperatures
The operating temperatures of hardware devices directly affect their
life time and their functionality. To avoid shortening the life times of
the hardware components, ensure that the operating temperature of
the dSPACE system does not exceed the specified ambient
temperature, for example, due to improper installation.
Objective
s
Accessories
t
252
s
DS1103 Hardware Installation and Configuration November 2014
