Installing the Hardware
dSPACE’s real‑time boards can be installed in the host PC or in an
expansion box connected to the PC via Ethernet or a bus interface.
An expansion box is an enclosure to be used for dSPACE boards only.
It provides 20 (PX20), 10 (PX10) or 4 (PX4) full‑size 16‑bit PC/AT slots
with the standard 0.8 inch (20.3 mm) spacing.
Objective
If you order the DS1103 together with an expansion box, the DS1103
is not inserted in the expansion box. The board is shipped separately
to avoid damage to itself and to the expansion box during
transportation.
Shipment with expansion
box
Information in this section
Resource Requirements of dSPACE Boards
Depending on the installation, dSPACE boards require resources in the
host PC and the expansion box.
31
Setting up the DS1103
Before inserting the DS1103 in the host PC or expansion box, you have to
check if any of the board's default settings must be changed.
34
Installing the DS1103
After setting up the DS1103, you can install it in your host PC or in an
expansion box.
37
Installing a Connector Panel
CP and CLP connector panels provide easy-to-use connections between
the board and external devices.
42
Installing AutoBox/Tandem-AutoBox in a Vehicle
AutoBox is an expansion box for in‑vehicle applications. After the dSPACE
boards are installed in an AutoBox, the AutoBox itself has to be installed
in a vehicle.
45
Where to go from here
DS1103 Hardware Installation and Configuration November 2014
29
