References
• BNC Connectors (CP1 ... CP28) on page 129
• Incremental Encoder Interface Connectors (CP32 ... CP37, CP39) on page 133
• Master PPC UART RS422 Connector (CP42) on page 137
• Slave DSP UART RS232 Connector (CP41) on page 136
• Slave DSP UART RS422 Connector (CP43) on page 137
• Slave I/O Connector (CP31) on page 132
Related topics
Conflicting I/O Features
There are I/O features that share the same board resources.
Conflicts concerning single I/O channels There are conflicts that
concern single channels of an I/O feature. The dSPACE board provides
only a limited number of I/O pins. The same pins can be shared by
different I/O features. However, a pin can serve as the I/O channel for
only one feature at a time.
Conflicts concerning an I/O feature as a whole There are
conflicts that concern the use of an I/O feature as a whole. Suppose
two I/O features of the dSPACE board use the same on‑board timer
device. In this case, only one of the two I/O features can be used at a
time. The other feature is completely blocked.
Types of I/O conflicts
s
Mapping of I/O Signals
t
152
s
DS1103 Hardware Installation and Configuration November 2014
