The following I/O features of the DS1103 conflict with other
I/O features:
n Conflicts for the Serial Interface on page 153
n see Conflicts for Synchronizing I/O Features of the Master PPC
on page 153
n Conflicts for the Slave DSP ADC Unit on page 154
n Conflicts for the Slave DSP Bit I/O Unit on page 154
n Conflicts for Slave DSP 1
‑ Phase PWM Signal Generation (PWM)
on page 155
n Conflicts for Slave DSP 3 ‑ Phase PWM Signal Generation (PWM3)
on page 156
n Conflicts for Slave DSP Space Vector PWM Signal
Generation (PWMSV) on page 157
n Conflicts for Slave DSP Square
‑ Wave Signal Generation (D2F)
on page 157
n Conflicts for Slave DSP PWM Signal Measurement (PWM2D)
on page 158
n Conflicts for Slave DSP Square ‑ Wave Signal Measurement (F2D)
on page 158
Conflicts for the DS1103
The master PPC of the DS1103 supports only one serial interface. It
can be configured as either RS232 or RS422 transceiver.
Conflicts for the Serial
Interface
The following I/O features of the DS1103 conflict with the
synchonizing I/O features of the master PPC.
Conflicts for Synchronizing
I/O Features of the Master
PPC
Synchronizing I/O Features of
the Master PPC *)
Signal Conflicting I/O Feature **)
Bit
(RTI)
Bit
(RTLib)
Ch
(RTI)
Ch
(RTLib)
ST1PWM
n Slave DSP PWM int
n Slave DSP Bit I/O Unit
Group 2 bit 3
*) Related RTI blocks and RTLib
functions:
n DS1103SYNC_IO_SETUP
DS1103MASTER_SYNCINT
n See Synchronous I/O Trigger
( DS1103 RTLib Reference)
**) Related RTI blocks and RTLib functions:
Slave DSP PWM int:
n DS1103SLAVE_PWMINT
n See ds1103_slave_dsp_pwm3_int_init
Slave DSP Bit I/O Unit:
n DS1103SL_DSP_BIT_IN_Cx
DS1103SL_DSP_BIT_OUT_Cx
n See Slave DSP Bit I/O Unit ( DS1103 RTLib Reference)
s
Conflicting I/O Features
t
DS1103 Hardware Installation and Configuration November 2014
153
