The following I/O features of the DS1103 conflict with Slave DSP
Space Vector PWM Signal Generation:
Conflicts for Slave DSP
Space Vector PWM Signal
Generation (PWMSV)
Slave DSP Space Vector PWM
Signal Generation (PWMSV) *)
Signal Conflicting I/O Feature **)
Ch
(RTI)
Ch
(RTLib)
Ch
(RTI)
Ch
(RTLib)
Conflicts Concerning Slave DSP 3‑Phase PWM Signal Generation as a Whole
n If you perform 3‑phase PWM signal generation (PWM3) or square‑wave signal generation (D2F), you cannot generate
space vector PWM signals at the same time.
*) Related RTI blocks and RTLib
functions:
n DS1103SL_DSP_PWMSV
n See Slave DSP PWMSV
Generation ( DS1103 RTLib
Reference)
**) Related RTI blocks and RTLib functions:
3-phase PWM signal generation (PWM3):
n DS1103SL_DSP_PWM3
n See Slave DSP PWM3 Generation ( DS1103 RTLib Reference)
D2F:
n DS1103SL_DSP_D2F
n See Square Wave Signal Generation (D2F) ( DS1103 RTLib Reference)
The following I/O features of the DS1103 conflict with Slave DSP
Square‑Wave Signal Generation:
Conflicts for Slave DSP
Square‑Wave Signal
Generation (D2F)
Slave DSP Square‑Wave Signal
Generation (D2F) *)
Signal Conflicting I/O Feature **)
Ch
(RTI)
Ch
(RTLib)
Ch
(RTI)
Ch
(RTLib)
Conflicts Concerning Slave DSP Square‑Wave Signal Generation as a Whole
n If you perform 3‑phase or space vector PWM signal generation (PWM3 or PWMSV), you cannot generate square‑wave
signals at the same time.
Conflicts Concerning Single Channels
Ch 4 Ch 4 ST2PWM
n Slave DSP Bit I/O unit n Bit 7 n Group 2, bit
4
n PWM n Ch 1 n Ch 1
*) Related RTI blocks and RTLib
functions:
n DS1103SL_DSP_D2F
n See Square Wave Signal
Generation (D2F) ( DS1103
RTLib Reference)
**) Related RTI blocks and RTLib functions:
PWM3/PWMSV:
n DS1103SL_DSP_PWM3
DS1103SL_DSP_PWMSV
n See Slave DSP PWM3 Generation/Slave DSP PWMSV Generation
( DS1103 RTLib Reference)
Slave DSP Bit I/O Unit:
n DS1103SL_DSP_BIT_IN_Cx
DS1103SL_DSP_BIT_OUT_Cx
n See Slave DSP Bit I/O Unit ( DS1103 RTLib Reference)
PWM:
n DS1103SL_DSP_PWM
n See Slave DSP PWM Generation ( DS1103 RTLib Reference)
s
Conflicting I/O Features
t
DS1103 Hardware Installation and Configuration November 2014
157
