Slave DSP Bit I/O Unit *) Signal Conflicting I/O Feature **)
Bit
(RTI)
Bit
(RTLib)
Ch
(RTI)
Ch
(RTLib)
Group 2, bit 3 ST1PWM
n Slave DSP PWM int
n Synchronizing I/O Features of the
Master PPC
*) Related RTI blocks and RTLib
functions:
n DS1103SL_DSP_BIT_IN_Cx
DS1103SL_DSP_BIT_OUT_Cx
n See Slave DSP Bit I/O Unit
( DS1103 RTLib Reference)
**) Related RTI blocks and RTLib functions:
Slave DSP ADC unit:
n DS1103SL_DSP_BIT_IN_Cx
DS1103SL_DSP_BIT_OUT_Cx
n See Slave DSP Bit I/O Unit ( DS1103 RTLib Reference)
PWM:
n DS1103SL_DSP_PWM
n See Slave DSP PWM Generation ( DS1103 RTLib Reference)
D2F:
n DS1103SL_DSP_D2F
n See Square Wave Signal Generation (D2F) (
DS1103 RTLib Reference)
PWM2D:
n DS1103SL_DSP_PWM2D
n
See Slave DSP PWM Measurement (PWM2D) ( DS1103 RTLib
Reference)
F2D:
n DS1103SL_DSP_F2D
n See Square Wave Signal Generation (D2F) (
DS1103 RTLib Reference)
Slave DSP PWM int:
n DS1103SLAVE_PWMINT
n See ds1103_slave_dsp_pwm3_int_init ( DS1103 RTLib Reference)
Synchronizing I/O Features of the Master PPC:
n DS1103SYNC_IO_SETUP
DS1103MASTER_SYNCINT
n See Synchronous I/O Trigger ( DS1103 RTLib Reference)
The following I/O features of the DS1103 conflict with Slave DSP
1‑Phase PWM Signal Generation:
Conflicts for Slave DSP
1‑Phase PWM Signal
Generation (PWM)
Slave DSP 1‑Phase PWM Signal
Generation (PWM) *)
Signal Conflicting I/O Feature **)
Ch
(RTI)
Ch
(RTLib)
Ch
(RTI)
Ch
(RTLib)
Conflicts Concerning Slave DSP 1‑Phase PWM Signal Generation as a Whole
n If you use channel 4 of D2F, you cannot generate 1‑phase PWM signals at the same time.
Conflicts Concerning Single Channels
Ch 1 Ch 1 ST2PWM Slave DSP Bit I/O unit Bit 7 Group 2, bit 4
