b Part Names and Their Functions
chap.1
20
Master ejection box
lid release lever
Master ejection box
lever
LED
JOG switch 1
(Drum rotator switch 1)
Master ejection core
Master ejection sectionMaster feed section
Drum bar
Drum handle
Drum securing
lever
Ink puck holder
release lever
Ink puck
Master clump
Drum section
Master cut switch
Cutter
Platen roller
Thermal head
440BBe
