b Part Names and Their Functions
chap.1
21
JOG switch 2
(Drum rotator switch 2)
Paper aligning lever
Jump plate
Top blow fun
Paper stacker guide
Paper stopper
S2-ADF
connector cover
(Optional)
Interface kit II
(Optional)
Connectors (Optional)
Print tray
440CCe
