Duplo DUPRINTER DP-430 - Page 235

237
c HELP Mode Function and Operation Procedures
chap.7
1. Functions
H-15
(1) Function testingHELP mode
2. Operation procedure
Accessing HELP modes
a See page 213
(1) Checking the movement amount of printing position(top/bottom)
(1) Checking the movement amount of printing position(top/bottom)
qAccess HELP mode H-15, and press the PRINT key.
¡The movement amount of printing position(top/bottom) is
displayed.
HELP-015
1 : Home position
111 : Limit 1
111 : Limit 2
Top/ bottom function check
a To exit the HELP mode
: Turn the power switch OFF.
a
To access another HELP mode
:
Enter the desired mode number
using the numeric keys.
wPress the STOP key.
The HELP mode selection display will reappear.
Value
