244
c HELP Mode Function and Operation Procedures
chap.7
ABCD Item Setting
0***
Sign flag
Shortens by the set amount for the
lower 3 digits.
1***
Lengthens by the set amount for
the lower 3 digits.
*000
Set amount
Standard (initial value)
Maximum
*001
*010
*011
*100
*101
*110
*111
1 rank: 0.125%
ePress the [=] key.
The correction amount will be memorized in the battery PCB unit's
EEPROM. During memorization,"SAVE" will be displayed.
Do not turn off the power before the "SAVE" display has disappeared.
1. Functions
(1) Master make magnification / line progression
direction setting
(1)
Setting of master make magnification / line progression
direction setting
H-22
(1) Adjustment / specification settingHELP mode
¡During memorization:
IMPORTANT :
2. Operation procedure
Accessing HELP modes
a
See page 213
qAccess HELP mode H-22, and press the PRINT key.
wUse the [0] and [1] numeric keys to enter a 4-place binary
value for the desired correction amount.
See the table below for 4-place binary values and the corresponding
correction amounts.
a
To exit the HELP mode
: Turn the power switch OFF.
a
To access another HELP mode
:
Enter the desired mode number
using the numeric keys.
rPress the STOP key.
The HELP mode selection display will reappear.
A B C D
- SAVE -
To Next Page
