A B C D
H-80
(1) Adjustment / specification settingHELP mode
ePress the [=] key.
The correction amount will be memorized in the battery PCB unit's
EEPROM. During memorization,"SAVE" will be displayed.
Do not turn off the power before the "SAVE" display has disappeared.
1. Functions
(1)
After master making, the machine prints 1 copy and stop,
S2-ADF option,Drum rotates once at tape insertion timing,
Drum rotation setting at tape insertion timing setting
¡Following items are indicated.
A : After master making, the machine prints 1 copy and stop
B : S2-ADF option
C : Drum rotates once at tape insertion timing
D : Drum rotation setting at tape insertion timing
(1)
After master making, the machine prints 1 copy and stop,
S2-ADF option,Drum rotates once at tape insertion timing,
Drum rotation setting at tape insertion timing setting
¡During memorization:
IMPORTANT :
2. Operation procedure
Accessing HELP modes
a
See page 213
qAccess HELP mode H-80, and press the PRINT key.
wUse the [0] and [1] numeric keys to enter a 4-place binary
value for the desired correction amount.
See the table below for 4-place binary values and the corresponding
correction amounts.
a
To exit the HELP mode
: Turn the power switch OFF.
a
To access another HELP mode
:
Enter the desired mode number
using the numeric keys.
rPress the STOP key.
The HELP mode selection display will reappear.
- SAVE -
