C
HAPTER
6
| VLAN Configuration
IEEE 802.1Q VLANs
– 163 –
N
OTE
:
The PVID, acceptable frame type, and ingress filtering parameters
for each interface within the specified range must be configured on either
the Edit Member by VLAN or Edit Member by Interface page.
WEB INTERFACE
To configure static members by the VLAN index:
1. Click VLAN, Static.
2. Select Edit Member by VLAN from the Step list.
3. Set the Interface type to display as Port or Trunk.
4. Modify the settings for any interface as required. Remember that
Membership Type cannot be changed until an interface has been added
to another VLAN and the PVID changed to anything other than 1.
5. Click Apply.
Figure 62: Configuring Static Members by VLAN Index
