C
HAPTER
8
| Spanning Tree Algorithm
Configuring Interface Settings for MSTP
– 214 –
The recommended range is listed in Table 9 on page 204.
The recommended path cost is listed in Table 10 on page 204.
The default path costs are listed in Table 11 on page 204.
WEB INTERFACE
To configure MSTP parameters for a port or trunk:
1. Click Spanning Tree, MSTP.
2. Select Configure Interface from the Step list.
3. Select Configure from the Action list.
4. Enter the priority and path cost for an interface
5. Click Apply.
Figure 105: Configuring MSTP Interface Settings
To display MSTP parameters for a port or trunk:
1. Click Spanning Tree, MSTP.
2. Select Configure Interface from the Step list.
3. Select Show Information from the Action list.
