C
HAPTER
18
| Multicast Filtering
Multicast VLAN Registration
– 469 –
WEB INTERFACE
To assign a static MVR group to a port:
1. Click Multicast, MVR.
2. Select Configure Static Group Member from the Step list.
3. Select Add from the Action list.
4. Select a VLAN and port member to receive the multicast stream, and
then enter the multicast group address.
5. Click Apply.
Figure 288: Assigning Static MVR Groups to a Port
To show the static MVR groups assigned to a port:
1. Click Multicast, MVR.
2. Select Configure Static Group Member from the Step list.
3. Select Show from the Action list.
4. Select the port for which to display this information.
Figure 289: Showing the Static MVR Groups Assigned to a Port
