C
HAPTER
24
| Authentication Commands
802.1X Port Authentication
– 632 –
â–
Current Identifier– The integer (0-255) used by the Authenticator to
identify the current authentication session.
â—† Backend State Machine
â–
State – Current state (including request, response, success, fail,
timeout, idle, initialize).
â–
Request Count– Number of EAP Request packets sent to the
Supplicant without receiving a response.
â–
Identifier (Server)– Identifier carried in the most recent EAP
Success, Failure or Request packet received from the Authentication
Server.
â—† Reauthentication State Machine
State – Current state (including initialize, reauthenticate).
EXAMPLE
Console#show dot1x
Global 802.1X Parameters
System-auth-control: Enabled
Authenticator Parameters:
EAPOL Pass Through : Disabled
Supplicant Parameters:
Identity Profile Username : steve
802.1X Port Summary
Port Name Status Operation Mode Mode Authorized
1/1 Disabled Single-Host ForceAuthorized N/A
1/2 Disabled Single-Host ForceAuthorized N/A
.
.
.
1/9 Disabled Single-Host ForceAuthorized Yes
1/10 Enabled Single-Host Auto Yes
802.1X Port Details
802.1X Authenticator is enabled on port 1/1
802.1X Supplicant is disabled on port 1/1
.
.
.
802.1X Authenticator is enabled on port 10
Reauthentication : Enabled
Reauth Period : 3600
Quiet Period : 60
TX Period : 30
Supplicant Timeout : 30
Server Timeout : 10
Reauth Max Retries : 2
Max Request : 2
Operation Mode : Multi-host
Port Control : Auto
Intrusion action : Block traffic
Supplicant : 00-e0-29-94-34-65
