C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 77 –
Chart Shows Interface, Etherlike, and RMON port statistics 128
Cable Test Performs cable diagnostics for selected port to diagnose any cable
faults (short, open etc.) and report the cable length
132
Trunk
Static 134
Configure Trunk 134
Add Creates a trunk, along with the first port member 134
Show Shows the configured trunk identifiers 134
Add Member Specifies ports to group into static trunks 134
Show Member Shows the port members for the selected trunk 134
Configure General 134
Configure Configures trunk connection settings 134
Show Information Displays trunk connection settings 134
Dynamic 137
Configure Aggregator Configures administration key for specific LACP groups 137
Configure Aggregation Port 134
Configure 134
General Allows ports to dynamically join trunks 137
Actor Configures parameters for link aggregation group members on the
local side
137
Partner Configures parameters for link aggregation group members on the
remote side
137
Show Information 143
Counters Displays statistics for LACP protocol messages 143
Internal Displays configuration settings and operational state for the local
side of a link aggregation
144
Neighbors Displays configuration settings and operational state for the remote
side of a link aggregation
146
Configure Trunk 137
Configure Configures connection settings 137
Show Displays port connection status 137
Show Member Shows the active members in a trunk 137
Statistics Shows Interface, Etherlike, and RMON port statistics 128
Chart Shows Interface, Etherlike, and RMON port statistics 128
Green Ethernet Adjusts the power provided to ports based on the length of the cable
used to connect to other devices
148
RSPAN Mirrors traffic from remote switches for analysis at a destination
port on the local switch
124
Traffic Segmentation 150
Configure Global Enables traffic segmentation globally 150
Table 4: Switch Main Menu (Continued)
Menu Description Page
