C HAPTER 3 | Using the Web Interface
Navigating the Web Browser Interface
– 78 –
Configure Session Configures the uplink and down-link ports for a segmented group of
ports
151
VLAN Trunking Allows unknown VLAN groups to pass through the specified
interface
152
VLAN Virtual LAN 155
Static
Add Creates VLAN groups 158
Show Displays configured VLAN groups 158
Modify Configures group name and administrative status 158
Edit Member by VLAN Specifies VLAN attributes per VLAN 160
Edit Member by Interface Specifies VLAN attributes per interface 160
Edit Member by Interface Range Specifies VLAN attributes per interface range 160
Dynamic
Configure General Enables GVRP VLAN registration protocol globally 165
Configure Interface Configures GVRP status and timers per interface 165
Show Dynamic VLAN 165
Show VLAN Shows the VLANs this switch has joined through GVRP 165
Show VLAN Member Shows the interfaces assigned to a VLAN through GVRP 165
Tunnel IEEE 802.1Q (QinQ) Tunneling 168
Configure Global Sets tunnel mode for the switch 172
Configure Interface Sets the tunnel mode for any participating interface 173
Protocol 174
Configure Protocol 175
Add Creates a protocol group, specifying supported protocols 175
Show Shows configured protocol groups 175
Configure Interface 177
Add Maps a protocol group to a VLAN 177
Show Shows the protocol groups mapped to each VLAN 177
IP Subnet 179
Add Maps IP subnet traffic to a VLAN 179
Show Shows IP subnet to VLAN mapping 179
MAC-Based 181
Add Maps traffic with specified source MAC address to a VLAN 181
Show Shows source MAC address to VLAN mapping 181
Mirror 183
Add Mirrors traffic from one or more source VLANs to a target port 183
Show Shows mirror list 183
Table 4: Switch Main Menu (Continued)
Menu Description Page
