C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 79 –
MAC Address 185
Learning Status Enables MAC address learning on selected interfaces 185
Static 187
Add Configures static entries in the address table 187
Show Displays static entries in the address table 187
Dynamic
Configure Aging Sets timeout for dynamically learned entries 188
Show Dynamic MAC Displays dynamic entries in the address table 189
Clear Dynamic MAC Removes any learned entries from the forwarding database and
clears the transmit and receive counts for any static or system
configured entries
190
Mirror Mirrors traffic matching a specified source address from any port on
the switch to a target port
191
Spanning Tree 193
Loopback Detection Configures Loopback Detection parameters 196
STA Spanning Tree Algorithm
Configure Global
Configure Configures global bridge settings for STP, RSTP and MSTP 197
Show Information Displays STA values used for the bridge 202
Configure Interface
Configure Configures interface settings for STA 203
Show Inform at on Displays interface settings for STA 207
MSTP Multiple Spanning Tree Algorithm 209
Configure Global 209
Add Configures initial VLAN and priority for an MST instance 209
Modify Configures the priority or an MST instance 209
Show Configures global settings for an MST instance 209
Add Member Adds VLAN members for an MST instance 209
Show Member Adds or deletes VLAN members for an MST instance 209
Show Information Displays MSTP values used for the bridge
Configure Interface 213
Configure Configures interface settings for an MST instance 213
Show Information Displays interface settings for an MST instance 213
Traffic
Rate Limit Sets the input and output rate limits for a port 217
Storm Control Sets the broadcast storm threshold for each interface 219
Table 4: Switch Main Menu (Continued)
Menu Description Page
