9-4 Modbus - Comparison of Parameters and Registers
Daniel / Enron Modicon
Mnemonic
Modbus-Register
4002 4002 CalibrationCountDB
4003 4003 CalValveStateDB
4004
4005
4004
4005
LinearizerError#DB
4006 4006 ParamAccessModeDB
4011..4026 4011..4026 ProgramVersionDB
8001..8012
8021..8032
5001..5024
5041..5064
MeasBufValues#DB
9001
9002
6001..6002
6003..6004
Concentration#DB
9003
9004
6005..6006
6007..6008
RawValueConcentration#DB
9005
9006
6009..6010
6011..6012
ZeroOffset#DB
9007
9008
6013..6014
6015..6016
TemperatureOffset#DB
9009
9010
6017..6018
6019..6020
CrossInterferenceOffset#DB
9011
9012
6021..6022
6023..6024
SpanFactor#DB
9013
9014
6025..6026
6027..6028
TemperatureFactor#DB
9015
9016
6029..6030
6031..6032
PressureFactor#DB
9017
9018
6033..6034
6035..6036
CorrRawValueConc#DB
9019
9020
6037-6038
6039..6040
MaxValue#DB
9021
9022
6041..6042
6043..6044
LinearNormVal#DB
9023
9024
6045..6046
6047..6048
NormConcentration#DB
9025 6049..6050 AirPressureDB
9027
9028
6053..6054
6055..6056
Temperature#DB
9029
9030
6057..6058
6059..6060
SourceCurrent#DB
9031
9032
6061..6062
6063..6064
StartOfRange#DB
9033
9034
6065..6066
6067..6068
EndOfRange#DB
9035
9036
6069..6070
6071..6072
ZeroGasValue#DB
9037
9038
6073..6074
6075..6076
SpanGasValue#DB
9039
9040
6077..6078
6079..6080
LinearMaxInFac#DB
9041..9043
6081..6086 ADC_Temp1CoeffsDB (A0, A1, A2)
This list is ordered by the Daniel/
Enron Modbus register column.
Any "#" is a wildcard, to be replaced by
"1" or "2" for the desired measuring
channel. In this case the upper register
line is assigned to channel 1, the lower
line to channel 2.
