X-STREAM
Emerson Process Management GmbH & Co. OHG 9-21
Instruction Manual
HASAxE-IM-HS
05/2006
9 Modbus
9-4 Modbus - Comparison of Parameters and Registers
Daniel / Enron Modicon
Mnemonic
Modbus-Register
9044..9046 6087..6092 ADC_Temp2CoeffsDB (A0, A1, A2)
9047..9050
9051..9054
6093..6100
6101..6108
ToffCorrCoeffs#DB (A0, A1, A2, A3)
9055..9058
9059..9062
6109..6116
6117..6124
TfactCorrCoeffs#DB (A0, A1, A2, A3)
9063..9066
9067..9070
6125..6132
6133..6140
PfactCorrCoeffs#DB (A0, A1, A2, A3)
9071..9075
9076..9080
6141..6150
6151..6160
LinearCoeffs#DB (A0, A1, A2, A3, A4)
9081..9082
9083..9084
6161..6164
6165..6168
ADC_Isrc#CoeffsDB (A0, A1)
9085
9086
6169..6170
6171..6172
TcntCorrCoeff#DB
9087..9088 6173..6176 PressSensorCoeffsDB (A0, A1)
9089
9090
6177..6178
6179..6180
CrossInterferenceFact#DB
9091
9093
6181..6182
6185..6186
PVAunitFactor#DB
9092
9094
6183..6184
6187..6188
PVAunitOffset#DB
9095
9097
6189..6190
6193..6194
AOutStartRange#DB
9096
9098
6191..6192
6195..6196
AOutEndRange#DB
9099
9100
6197..6198
6199..6200
MeasBufAvg#DB
9101
9103
6201..6202
6205..6206
Limit1Level#DB
9102
9104
6203..6204
6207..6208
Limit2Level#DB
9105
9106
6209..6210
6211..6212
RawValueTfact#DB
9107
9108
6213..6214
6215..6216
LowestEndRng#DB
9109
9110
6217..6218
6219..6220
RawValueTemperature#DB
This list is ordered by the Daniel/
Enron Modbus register column.
Any "#" is a wildcard, to be replaced by
"1" or "2" for the desired measuring
channel. In this case the upper register
line is assigned to channel 1, the lower
line to channel 2.
