1. GENERAL SPECIFICATIONS
1.1 Slip Section
1.1.1 Printing Specifications
1) Printing method: Serial impact dot matrix
2) Head wire configuration: 9-pin vertical line, wire pitch 1/72 inch
3) Head wire diameter: 0.29 mm (.01")
4) Printing direction: Bidirectional, minimum distance printing
5) Printing speed: Refer to Table 1.1.1
6) Characters per line: Refer to Table 1.1.1
7) Characters per inch: Refer to Table 1.1.1
8) Kanji characters print: Unidirectional two-pass printing
1.1.2 Character Specifications
1) Number of characters: Alphanumeric characters: 95
International characters: 32
Extended graphics: 128 ´ 10 pages
(including one space page)
Multilingual character model supports printing with one of the
following characters:
À Japanese Kanji (Two-pass printing font)
JIS (JIS X0208-1990) Level 1, Level 2
Á Chinese Kanji (Two-pass printing font)
7580 (GB2312)
 Taiwanese Kanji
13494 (Big 5)
à Thai character (3-pass printing font)
128 characters ´ 7 pages (133 character types)
2) Character structure: Font A: 9 ´ 9 3-dot spacing (in half dot units)
Font B: 7 ´ 9 2-dot spacing (in half dot units)
Kanji: 16 ´ 16 Left 0-dot, Right 2-dot spacing (in half dot units)
Thai characters
Font A: 9 ´ 27 3-dot spacing (in half dot units)
Font B: 7 ´ 27 2-dot spacing (in half dot units)
Larger spacing can be changed by using
ESC SP
or
FS S
.
3) Character size: Refer to Table 1.1.1
