CONFIDENTIAL
SHEET
152
NO.
SHEET
REVISION
E
TITLE
TM-H5000
II
IIII
II
series
Specification
(STANDARD)
NEXT
153
GS /
m
[Name] Print downloaded bit image
[Format] ASCII GS /
m
Hex 1D 2F
m
Decimal 29 47
m
[Range] 0 £
m
£ 3, 48 £
m
£ 51
[Description] Prints a downloaded bit image using the mode specified by
m
.
m
selects a mode from the table below:
< paper roll >
m
Mode Vertical Dot Density (DPI) Horizontal Dot Density (DPI)
0, 48 Normal 180 180
1, 49 Double-width 180 90
2, 50 Double-height 90 180
3, 51 Quadruple 90 90
<slip>
m
Mode Vertical Dot Density (DPI)
Maximum Number of Dots in
Horizontal
0, 48 Normal Not available 800 dots
1, 49 Double-width Available 400 dots
[Notes] · This command is ignored if a downloaded bit image has not been defined.
· In standard mode, this command is effective only when there is no data in the
print buffer.
· This command has no effect in the print modes (emphasized, double-strike,
underline, character size, white/black reverse printing, or 90° rotated character
etc.), except for upside-down printing mode.
· If the downloaded bit image to be printed exeeds the printable area, the excess
data is not printed.
· Refer to Figure 3.12.3 for the downloaded bit image development position in
page mode.
· If the printing area width set by
GS L
and
GS W
is less than one line in vertical,
the following processing is executed only on the line in question:
① The printing area width is extended to the right up to one line in vertical. In
this case, printing does not exceed the printable area.
② If the printing area width cannot be extended by one line in vertical, the left
margin is reduced to accommodate one line in vertical.
One line in vertical means 1 dot (one half dot for the slip) in normal (
m
= 0, 48)
and double-height (2,50), 2 dots (two half dot for the slip) in double-width
(
m
= 1, 49) and quadruple (
m
= 3, 51) modes.
· The user-defined
bit image
is printed on the selected paper set by the
ESC c 0
command.
[Reference]
GS
*
**
*
