APPENDIX E: TRANSMISSION STATUS IDENTIFICATION
Because the specified status bits transmitted from the TM-H5000 are fixed, the user can confirm
the command to which the status belongs, as shown in the following table.
Command & Function Status Reply
GS
I
II
I
<0**0****>B
GS r
<0**0****>B
XON <00010001>B
XOFF
<0**1**11>B
DLE EOT 1~5
<0**1**10>B
ASB (1st byte)
<0**1**00>B
ASB (2nd to 4th bytes)
<0**0****>B
(When the printer is used with the MICR reader.)
Command & Function Status Reply
FS a 0, FS b
(header) <01011111>B
DLE EOT BS 1
<0**1**10>B
When the printer receives header (<5F>H) transmitted when
FS a 0
or
FS b
is executed, status identification must not be performed until NUL (<00>H) is
received.
