TM-H5000
II
IIII
II
series
Specification
(STANDARD)
4. CASE SPECIFICATIONS
4.1 External Dimensions and Weight
Height: 201 mm (7.91")
Width: 252 mm (9.92")
Depth: 331 mm (13.03") (except for the protrusion)
Weight: Approximately 6.5 kg (14.3 lbs)
(All the numeric values are typical.)
4.2 Color
EPSON standard color (ECW)
4.3 External Appearance
Figure 4.3.1 External Appearance
Materials for the external: 94V-0
201
[Unit: mm]
