CONFIDENTIAL
SHEET
19
NO.
SHEET
REVISION
E
TITLE
NEXT
20
TM-H5000
II
IIII
II
series
Specification
(STANDARD)
2. CONFIGURATION
2.1 Interface
2.1.1 RS-232 serial interface
2.1.1.1 Specifications
Data transmission: Serial
Synchronization: Asynchronous
Handshaking: DTR/DSR or XON/XOFF control
Signal levels: MARK = -3 to -15 V: Logic "1"
SPACE = +3 to +15 V: Logic "0"
Stop bits: 1 or more
Connector (printer side): Female DSUB-25 pin connector
The data word length, baud rate, and parity depend on the DIP switch settings. (Refer to
Section 3.3.3.) The stop bit for the printer side is fixed to 1.
2.1.1.2 Switching between on-line and off-line
The printer does not have an on-line/off-line switch. The printer goes off-line:
· Between when the power is turned on (including reset using the interface) and when the
printer is ready to receive data.
· During the self-test.
· When the cover is open (the cover for the paper sheet selected by
ESC c 0
).
· During paper feeding using the paper feed switch.
· When the printer stops printing due to a paper-end (only when the paper roll is not
present).
· When an error has occurred.
To Next Page
