Epson TM-H5000II series User Manual

CONFIDENTIAL
SHEET
12
NO.
SHEET
REVISION
E
TITLE
TM-H5000
II
IIII
II
series
Specification
(STANDARD)
NEXT
13
1.2.3 Auto Cutter
Partial cut: Cutting with one point left uncut
NOTE:
To prevent dot displacement, after cutting, paper must be fed approximately 1 mm
(14/360 inches) or more before printing.
1.2.4 Paper Roll Supply Device Section
1) Supply method: Drop-in paper roll
2) Near-end sensor
a) Detection method: Microswitch
b) Paper roll spool diameter: Inside: 12 mm (.47")
Outside: 18 mm (.71")
c) Near-end adjustment: Adjusting screw
d) Remaining amount: Fixed position #1 (approximately 23 mm (0.9”))
#2 (approximately 27 mm (1.06”)
(The adjusting screw has two positions.)
Refer to Appendix D.
3) Paper roll end detection
a) Detection method: Reflective light sensor
NOTE:
You can use a command to stop printing upon detection of a paper near-end.
1.2.5 Paper Specification
1) Paper type: Specified thermal paper
2) Form: Paper roll
3) Paper width: 79.5 ± 0.5 mm (3.13" ± 0.02")
4) Paper roll size: Roll diameter: Maximum 83 mm
Take-up paper roll width: 80 ±
10
00
.
.
mm
(3.15" ±
004
0 020
."
."
)
5) Specified paper: Specified thermal roll paper, NTP080-80
In Japan: Nakagawa, Seisakujo
In U.S.A.: Nakagawa Mfg. (USA) Inc.
In Europe: Nakagawa Mfg. (Europe) GmbH
In Southeast Asia: N.A.K. Mfg. (Malaysia) SDN BHD
[Original paper: TF50KS-E Nippon Paper Industries Co.,Ltd.,]
The following paper can be used instead of the specified
paper above:
Original paper: PD 160R (Oji Paper Mfg. Co. Ltd.)
Original paper: AF50KS-E (Jujo Thermal Oy
(Finland))
Original paper: P350(F380), P310, P300
(Kanzaki Specialty Papers, Inc.
(U.S.A.))
6) Paper roll spool diameter: Inside: 12 mm (.47")
Outside: 18 mm (.71")
NOTE:
Paper must not be pasted to the paper roll spool.
