CONFIDENTIAL
SHEET
144
NO.
SHEET
REVISION
E
TITLE
TM-H5000
II
IIII
II
series
Specification
(STANDARD)
NEXT
145
·
This command feeds dots (for the height
n
of the NV bit image) in normal and
double-width modes, and (for the height
n
´
2 of the VN bit image) in double-
height and quadruple modes, regardless of the line spacing specified by
ESC 2
or
ESC 3
.
·
After printing the bit image, this command sets the print position to the beginning
of the line and processes the data that follows as normal data.
[References]
FS q
FS q
n [x
L
x
H
y
L
y
H
d1...dk]1...[x
L
x
H
y
L
y
H
d1...dk]n
[Name] Define NV bit image
[Format] ASCII FS q
n [x
L
x
H
y
L
y
H
d1...dk]1...[ x
L
x
H
y
L
y
H
d1...dk]n
Hex 1C 71
n [x
L
x
H
y
L
y
H
d1...dk]1...[ x
L
x
H
y
L
y
H
d1...dk]n
Decimal 28 113
n [x
L
x
H
y
L
y
H
d1...dk]1...[ x
L
x
H
y
L
y
H
d1...dk]n
[Range] 1 £
n
£ 255
0 £
x
L
£ 255
0 £
x
H
£ 3 (when 1 £ (
x
L
+
x
H
´ 256) £ 1023
0 £
y
L
£ 1 (when 1 £ (
y
L
+
y
H
´ 256) £ 288
0 £
d
£ 255
k
= (
x
L
+
x
H
´ 256) ´ (
y
L
+
y
H
´ 256) ´ 8
Total defined data area = 3M bits (384K bytes)
[Description] Define
the
NV bit image specified by
n
.
·
n
specifies the number of the defined NV bit image.
·
x
L
,
x
H
specifies (
x
L
+
x
H
´ 256) ´ 8 dots in the horizontal direction for the NV bit
image you are defining.
·
y
L
,
y
H
specifies (
y
L
+
y
H
´ 256) ´ 8 dots in the vertical direction for the NV bit
image you are defining.
[Notes] · Frequent write command execution
may cause damage the NV memory.
Therefore, it is recommended to write the NV memory 10 times or less a day.
· The printer executes a hardware reset after the procedure to place the image
into the non-volatile memory. Therefore, user-defined characters, downloaded
bit images, and macros should be defined only after completing this command.
The printer clears the receive and print buffers and resets the mode to the
mode that was in effect at power on. At this time, DIP switch settings are
checked again.
· During processing this command, the printer is in BUSY when writing the data
to the user NV memory and stops receiving data. Therefore it is prohibitted to
transmit the data including the real-time commands during the execution of this
command.
· This command cancels all NV bit images that have already been defined by this
command. The printer can not redefine only one of several data definitions
previously defined. In this case, all data needs to be sent again.
· From the beginning of the processing of this command till the finish of hardware
reset, mechanical operations (including initializing the position of the printer
head when the cover is open, paper feeding by using the PAPER FEED button,
etc.) cannot be
execut
ed.
To Next Page
