· NV bit image means a bit image which is defined in a non-volatile memory by
FS q
and printed by
FS p
.
· In standard mode, this command is effective only when processed at the
beginning of the line.
· In page mode, this command is not effective.
· This command is effective when 7 bytes <FS~yH> is processed as a normal
value.
· When the amount of data exceeds the capacity left in the range defined by
x
L
,
x
H
, y
L
, y
H
, the printer processes
x
L
, x
H
, y
L
, y
H
out of the defined range.
· In the first group of NV bit images, when any of the parameters
x
L
, x
H
, y
L
, y
H
is
out of the definition range, this command is disabled.
· In groups of NV bit images other than the first one, when the printer processes
x
L
, x
H
, y
L
, y
H
out of the defined range, it stops processing this command and
starts writing into the non-volatile images. At this time, NV bit images that
haven’t been defined are disabled (undefined), but any NV bit images before
that are enabled.
· The
d
indicates the definition data. In data (
d
) a 1 bit specifies a dot to be
printed and a 0 bit specifies a dot not to be printed.
· This command defines
n
as the number of a
NV bit image. Numbers rise in
order from NV bit image 01H. Therefore, the first data group
[x
L
x
H
y
L
y
H
d1...dk]
is NV bit image 01H, and the last data group
[x
L
x
H
y
L
y
H
d1...dk]
is NV
bit image
n.
The total agrees with the number of NV bit images specified by
command
FS p
.
· A definition data of a NV bit image consists of
[x
L
x
H
y
L
y
H
d1...dk].
Thefore,
when only one NV bit image is defined,
n
=1.
· The printer processes a data group
[x
L
x
H
y
L
y
H
d1...dk]
once.
· The printer uses ([data: (
x
L
+
x
H
´ 256) ´ (
y
L
+
y
H
´ 256) ´ 8] + [header :4])
bytes of non-volatile memory.
· The definition area in this printer is a maximum of 3M bits (384K bytes). This
command can define several NV bit images, but cannot define a bit image data
whose total capacity [bit image data + header] exceeds 3M bytes (384K bytes).
· The printer is busy immediately before writing into non-volatile memory,
regardless of the setting of DIP switch 2-1.
· The printer does not transmit ASB status and executes status detection during
processing of this command even when ASB is specified.
· This command defines NV bit image printing on a paper roll without being
affected by the sheet setting selected in
ESC c 1
.
· When this command is received during macro definition, the printer ends macro
definition, and begins executing this command.
· Once a NV bit image is defined, it is not erased by executing
ESC @
, reset,
and power off.
· This command executes only definition of a NV bit image and does not execute
printing. Printing of the NV bit image is executed by the
FS p
command.
[Reference]
FS p
