CONFIDENTIAL
SHEET
15
NO.
SHEET
REVISION
E
TITLE
TM-H5000
II
IIII
II
series
Specification
(STANDARD)
NEXT
16
1.3.2 Electrical Characteristics
1) Supply voltage: +24 VDC ± 10% (optional power supply: EPSON PS-170)
Ripple voltage: 300 mVpp or less
(only when the printer is used with the MICR reader)
2) Current consumption (at 24V except for drawer kickout driving)
Slip: Operating: Mean: Approximately 1.9A
(Character font A a-N all columns printing)
Peak: Approximately 8.0A (20 msec)
When the print platen is released: 2.0A (200 msec)
Receipt: Operating: Mean: Approximately 1.7A
(Character font A a-N all columns printing)
Peak: Approximately 7.7A
Low power consumption mode:
Mean: Approximately 1.2A
(Character font A a-N all columns printing)
Peak: Approximately 6.6A
Standby: Mean: Approximately 0.3A
1.3.3 EMI and Safety Standards Applied (EMC is tested using the EPSON PS-170
power supply)
1) Europe: CE marking
EN55022
EN50082-1
EN45501
Safety Standard: TÜV (EN 60950)
2) North America:
EMI: FCC Class A
Safety standards: UL1950-2TH-D3
C-UL
3) Japan: EMI: VCCI Class 1
4) China (the People’s Republic of China):
Safety standards: GB4943-1995
5) Oceania: EMI: AS/NZS 3548 class B
Conditions of Acceptability
1) This component has been judged on the basis of the required spacing in the Standard for
Information Technology equipment, Including Electrical Business Equipment, UL 1950 and
CSA22.2 No. 950, Sub-clause 2.9, which would cover the component itself if submitted for
Listing.
2) This unit is intended to be supplied by a SELV circuit only.
3) The terminals and connectors have not been evaluated for field wiring.
4) Interface Connectors (DK, DM-D) are not intended for TNV connection.
