CONFIDENTIAL
SHEET
132
NO.
SHEET
REVISION
E
TITLE
TM-H5000
II
IIII
II
series
Specification
(STANDARD)
NEXT
133
ESC c 3
n
[Name] Select paper sensor(s) to output paper end signals
[Format] ASCII ESC c 3
n
Hex 1B 63 33
n
Decimal 27 99 51
n
[Range] 0 £
n
£ 255
[Description] Selects the paper sensor(s) to output paper end signals
· Each bit of
n
is used as follows:
Bit Off/On Hex Decimal Function
0 Off 00 0 Paper roll near-end sensor disabled
On 01 1 Paper roll near-end sensor enabled
1 Off 00 0 Paper roll near-end sensor disabled
On 02 2 Paper roll near-end sensor enabled
2 Off 00 0 Paper roll end sensor disabled
On 04 4 Paper roll end sensor enabled
3 Off 00 0 Paper roll end sensor disabled
On 08 8 Paper roll end sensor enabled
4 Off 00 0 TOF sensor disabled
On 10 16 TOF sensor enabled
5 Off 00 0 BOF sensor disabled
On 20 32 BOF sensor enabled
6, 7 - - - Undefined
[Notes] · It is possible to select multiple sensors to output signals. Then, if any of the
sensors detects a paper end, the paper end signal is output.
· Sensor is switched when executing this command. The paper end signal
switching be delayed depending on the receive buffer state.
· If either bit 0 or bit 1 is on, the paper roll near-end sensor is selected as the
paper sensor outputting paper-end signals
· If either bit 2 or bit 3 is on, the paper roll end sensor is selected as the paper
sensor outputting paper-end signals.
· When all the sensors are disabled, the paper end signal always outputs a paper
present status.
· The command is available only with a parallel interface and is ignored with a
serial interface.
[Default]
n
= 15
