CONFIDENTIAL
SHEET
172
NO.
SHEET
REVISION
E
TITLE
TM-H5000
II
IIII
II
series
Specification
(STANDARD)
NEXT
173
GS g 2
m n
L
n
H
[Name] Transmit maintenance counter
[Format] ASCII GS g 2
m n
L
n
H
Hex 1D 67 32
m n
L
n
H
Decimal 29 103 50
m n
L
n
H
[Range]
m
= 0
0 £ (
n
L
+(n
H
´256)) £ 65535
[Description] Transmits the specified maintenance counter.
·
m
is always set to 0.
·
n
L
,
n
H
specify the maintenance counter number to (
n
L
+(
n
H
´256)).
Counter number
Hex
Decimal
Counter
Type of
maintenance
counter
0A 10 Number of feeding lines (for slip) Resettable
0B 11 Number of printed characters (for slip) Resettable
14 20 Number of feeding lines (for paper roll) Resettable
15 21 Number of energizing head (for paper roll) Resettable
32 50 Number of auto-cutter operations Resettable
3C 60 Number of reading amount of MICR Resettable
46 70 Period of printer operation Resettable
8A 138 Number of feeding lines (for slip) Non-resettable
8B 139 Number of printed characters (for slip) Non-resettable
94 148 Number of feeding lines (for paper roll) Non-resettable
95 149 Number of energizing head (for paper roll) Non-resettable
B2 178 Number of auto-cutter operations Non-resettable
BC 188 Number of reading amount of MICR Non-resettable
C6 198 Period of printer operation Non-resettable
· If the value of the argument (
m
) is out of the specified range, this command is
ignored and data following are processed as normal data.
· If the counter number (
n
L
, n
H
) is not set, this command is ignored.
· After the data is ready to transmit, the printer executes the following process.
¬ Executes READY to BUSY. If it is already BUSY, the printer executes
nothing.
- Transmits [Header + Data + NUL].
® Executes BUSY to READY. If it is already BUSY for any other cause, the
printer executes nothing.
· The contents of [Header + DATA + NUL] are as follows:
Header: Hexadecimal = 5FH / Decimal = 95 (1 byte)
Data: Value of counters (1 to 10 bytes)
NUL: Hexadecimal = 00H / Decimal = 0 (1 byte)
To Next Page
