CONFIDENTIAL
SHEET
64
NO.
SHEET
REVISION
E
TITLE
NEXT
65
TM-H5000
II
IIII
II
series
Specification
(STANDARD)
3.3 Switches and Buttons
3.3.1 Power Button
The power button (a rocker switch) located on the lower left front of the printer turns the power
on or off.
NOTE:
Turn on the power only after connecting the power supply.
3.3.2 Panel Buttons
There are panel buttons on both the slip and receipt sections. All the panel buttons are disabled
by
ESC c 5
.
3.3.2.1 Slip
1) RELEASE button (non-locking push button)
[Function] Release paper
2) REVERSE button (non-locking push button)
[Function] Reverse paper feeding for the line spacing set by
ESC 2
and
ESC 3
3) FORWARD button (non-locking push button)
[Function] Feed paper for the line spacing set by
ESC 2
and
ESC 3
Paper feed is not executed without paper.
NOTE:
When the printer cover is open, the printer will not operate.
3.3.2.2 Receipt
FEED button: Non-locking push button
[Function] · If you push this button once and release it, the printer feeds paper for one line
based on the line spacing set by
ESC 2
and
ESC 3
. However, Paper feeding
using the FEED button cannot be performed under the following conditions:
① The paper roll end sensor detects a paper end
② When the printer cover is open.
· If you push this button when the printer is in the macro execution standby state,
the defined macro is executed.
· During self-test printing, you can stop the self test temporarily by pressing this
button and restart it by pressing the button again.
To Next Page
