TM-H5000
II
IIII
II
series
Specification
(STANDARD)
DLE DC4
n m t
[Name] Generate pulse at real time
[Format] ASCII DLE DC4
nmt
Hex 10 14
nmt
Decimal 16 20
nmt
[Range]
n
= 1
m
= 0, 1
1 £
t
£ 8
[Description] Outputs the pulse specified by t to connector pin m as follows:
m
Connector pin
0 Drawer kick-out connector pin 2.
1 Drawer kick-out connector pin 5.
The pulse ON time is [
t
´ 100 ms] and the OFF time is [
t
´ 100ms].
[Notes] · When the printer is in an error status when this command is processed, this
command is ignored.
· When the pulse is output to the connector pin specified while
ESC p
or
DEL
DC4
is executed while this command is processed, this command is ignored.
· The printer executes this command upon receiving it.
· With a serial interface model, this command is executed even when the printer
is off-line, the receive buffer is full, or there is an error status.
· With a parallel interface model, this command cannot be executed when the
printer is busy. This command is executed even when the printer is off-line or
there is an error status when DIP switch 2-1 is on.
· If print data includes the same character strings as this command, the printer
performs the same operation specified by this command. The user must
consider this.
· This command should not be used within the data sequence of another
command that consists of 2 or more bytes.
· This command is effective even when the printer is disabled with
ESC =
(Select
peripheral device).
[Reference]
ESC p
To Next Page
