CONFIDENTIAL
SHEET
150
NO.
SHEET
REVISION
E
TITLE
TM-H5000
II
IIII
II
series
Specification
(STANDARD)
NEXT
151
GS *
**
*
x y d1 ... d(x
´
´´
´
y
´
´´
´
8)
[Name] Define user-defined
bit image
[Format] ASCII GS *
x y d1 ... d(x
´
y
´
8)
Hex 1D 2A
x y d1 ... d(x
´
y
´
8)
Decimal 29 42
x y d1 ... d(x
´
y
´
8)
[Range] 1 £
x
£ 255
1 £
y
£ 48 (when paper roll is selected)
where
x
´
y
£ 1536 (when the paper roll is selected)
1 £
y
£ 255 (when slip is selected)
where
x
´
y
£ 404 (when the slip is selected)
0 £
d
£ 255
[Description] Defines a user-defined
bit image
using the number of dots specified by
x
and
y
·
x
specifies the number of dots in the horizontal direction.
·
y
specifies the number of dots in the vertical direction.
[Notes] · The number of dots in the horizontal direction is
x
´ 8, in the vertical direction it
is
y
´ 8.
· If
x
´
y
is out of the specified range, this command is disabled.
· The
d
indicates
bit image
data. Data (
d
) specifies a bit printed to 1 and not
printed to 0.
· A user-defined character and a user-defined
bit image
cannot be defined
simultaneously. When this command is executed, the user-defined character is
cleared.
· The downloaded bit image definition os cleared when:
¬
ESC @
is executed.
-
ESC &
is executed.
®
FS q
is executed.
¯ Printer is reset or the power is turned off.
· The user-defined bit image can be defined on the selected paper by the
ESC c 1
.
[Reference]
ESC &
,
ESC c 1
,
GS /
