CONFIDENTIAL
SHEET
10
NO.
SHEET
REVISION
E
TITLE
TM-H5000
II
IIII
II
series
Specification
(STANDARD)
NEXT
11
1.2 Receipt Section
1.2.1 Printing Specifications
1) Printing method: Thermal line printing
2) Dot density: 180 dpi ´ 180 dpi. The number of dots per 25.4 mm (1")
3) Printing direction: Unidirectional with friction feed
4) Printing width: 72 mm (2.83"), 512 dot positions
5) Characters per line (default): Font A: 42
Font B: 56
6) Character spacing (default): Font A: 0.28 mm (.01") (2 dots)
Font B: 0.28 mm (.01") (2 dots)
Programmable by control command.
7) Printing speed: High speed mode:
28.4 lines/second maximum
(1/6 inch feed) (at 24V, 20°C, Density level 2)
120 mm/second maximum
(4.72 inches/second maximum)
Speeds are switched depending on the applied
voltage to the printer and head temperature
conditions automatically.
Low power consumption mode:
Approximately 16.5 lines/second
(1/6 inch feed)
Approximately 70 mm/second
(approximately 2.76 inches/second)
When a ladder bar code is printed:
Approximately 42 mm/second
(approximately 1.7 inches/second)
NOTES:
· Printing speed may be slower depending on the data
transmission speed and the combination of control
commands.
· Low transmission speed may cause intermittent printing.
It is recommended to transmit data to the printer as
quickly as possible.
· High speed mode or low power consumption mode is
selected by a DIP switch. (Refer to Table 3.3.4 or 3.3.7).
8) Paper feed speed: Approximately 120 mm/second
(approximately 4.72 inches/second) (continuous paper
feeding)
9) Line spacing (default): 1/6 inch (4.23 mm)
Programmable by control command
