FS p n m
[Name] Print NV bit image
[Format] ASCII FS p
nm
Hex 1C 70 nm
Decimal 28 112 nm
[Range] 1 £ n £ 255
0 £
m £ 3 , 48 £ m £ 51
[Description] Prints a NV bit image
n using the mode specified by m .
m Mode Vertical Dot Density (DPI) Horizontal Dot Density (DPI)
0, 48 Normal 180 180
1, 49 Double-width 180 90
2, 50 Double-height 90 180
3, 51 Quadruple 90 90
·
n is the number of the NV bit image (defined using the
FS q
command).
·
m specifies the bit image mode.
[Notes] · NV bit image means a bit image which is defined in a non-volatile memory by
FS g
and printed by
FS p
.
·
This command is not effective when the specified NV bit image has not been
defined.
·
This command is available only when paper roll is selected using
ESC c 0.
·
In standard mode, this command is effective only when there is no data in the
print buffer.
· In page mode, this command is not effective.
·
This command is not affected by print modes (emphasized, double-strike,
underline, character size, white/black reverse printing, or 90
°
rotated characters,
etc.), except upside-down printing mode.
·
If the printing area width set by
GS L
and
GS W
for the NV bit image is less than
one vertical line, the following processing is executed only on the line in question.
However, in NV bit image mode, one vertical line means 1 dot (one half dot for
slip paper) in normal mode (
m
=
0, 48) and in double-height mode (
m
=
2, 50), and
it means 2 dots (two half dots for slip paper) in double-width mode (
m
=
1, 49) and
in quadruple mode (
m
=
3, 51).
¬
The printing area width is extended to the right in NV bit image mode up to
one line vertically. In this case, printing does not exceed the printable area.
-
If the printing area width cannot be extended by one line vertically, the left
margin is reduced to accommodate one line vertically.
·
If the downloaded bit image to be printed exceeds one line, the excess data is
not printed.
