CONFIDENTIAL
5
SHEET
App. 5
NO.
SHEET
REVISION
E
TITLE
NEXT
App. 6
TM-H5000
II
IIII
II
series
Specification
(STANDARD)
APPENDIX B: PAPER ROLL SETUP
B.1 Replacing the Ribbon Cassette in the Slip Section
1) Turn off the power.
2) Pull the front cover toward you and lift it up.
3) Remove the ribbon cassette.
4) Make sure that the print head is on the right side and turn the feed knob to take up any
slack in the ribbon. Then insert the new ribbon cassette.
(Note that if the ribbon is not correctly placed in the ribbon guide, when you insert slip paper
it may catch on the ribbon or become stained with ink from the ribbon.)
5) Push the front cover down and back.
B.2 Replacing the Paper Roll in the Receipt Section
1) Turn on the printer power.
2) Open the printer cover by pressing the cover open button.
3) Remove the spool of the used paper roll from the paper holder and load the new paper roll.
(Note the paper roll winding direction.)
4) Pull out some of the paper from the paper roll and close the printer cover.
To Next Page
