· When the counter values are transmitted, the printer converts them to the
character codes corresponding those decimal value, and transmits from the
most significant column. The range of transmitted data is [Hex: 30H to 39H /
Decimal: 48 to 57].
(Example 1) When the counter value is 78H, the transmitted data are (31H,
32H, 30H) corresponding to “120”.
(Example 2) When the counter value is 7CDH, the transmitted data are
(31H, 39H, 39H, 37H) corresponding to “1997”.
· When DTR/DSR control is selected, the printer transmits data consecutively
after confirming whether the host computer is ready to receive data. The
printer waits until the host is ready.
· When XON/XOFF control is selected, the printer transmits all data
consecutively without confirming whether the host computer is ready to receive
data. The data transmission must be consecutive, except for the XOFF code.
· With the parallel interface mode, the data buffer capacity (which is the memory
area to store all transmitted data except ASB status) is 99 bytes.
Data which exceeds 99 bytes are ignored.
· The printer transmits all data collectively without confirming whether the host is
ready to receive data. To receive all data correctly, 12 bytes or more space is
required in the receive buffer of the host.
· During data transmission, the printer ignores
DLE EOT
n
and
DLE EOT BS
n
.
Also, the printer does not transmit ASB even when the ABS is enabled.
Therefore, the user cannot confirm changes in the printer status during these
periods.
· Each maintenance counter has the following details. When the value of the
counter reaches the maximum, it becomes 0 at the next counting.
Counter Unit counting method Maximum value
Number of feeding
lines (for slip)
lines Counts when 4.23mm {24/144
inches} line feed is executed.
178, 956, 970
Number of printed
characters (for
slip)
characters Counts each 6 times of
energizing head for one
character.
715, 827, 882
Number of feeding
lines (for paper
roll)
lines Counts when 4.23mm {24/144
inches} line feed is executed.
143, 165, 576
Number of
energizing head
(for paper roll)
times Counts each time when the
thermal head is energized
when printing on the paper roll.
4, 294, 967, 295
Number of auto-
cutter operations
times Counts each time when the
auto-cutter executes a cutting
operation
4, 294, 967, 295
Number of reading
amount of MICR
times Counts each time when the
check paper is read.
4, 297, 967, 295
Period of printer
operation
hours Counts the operation hours
after turning on.
71, 582, 788
