Drawer kick-out connector status (
n
= 2, 50):
Bit Off/On Hex Decimal Function
0 Off 00 0 Drawer kick-out connector pin 3 is LOW.
On 01 1 Drawer kick-out connector pin 3 is HIGH.
1-3 - - - Undefined.
4 Off 00 0 Not used. Fixed to Off.
5, 6 - - - Undefined.
7 Off 00 0 Not used. Fixed to Off.
Slip Status (
n
= 3, 51)
The remaining print area (times of the number of dots in vertical for one
character) is transmitted as values from <00>H to <06>H.
The number of remaining dots Slip status
0 - 8 <00>H
9 - 17 <01>H
18 - 26 <02>H
27-35 <03>H
36 - 44 <04>H
45 - 53 <05>H
54 or more <06>H
When the slip is not selected, the status is <00>H.
[Reference]
DLE EOT
,
GS a
, Appendix E
