196
n
= 1: MICR status
Bit Off/On Hex Decimal Status
0 Off - - Not used. Fixed to Off.
1 On - - Not used. Fixed to On.
2 Off 00 0 MICR function selected.
On 04 4 MICR function not selected.
3 Off 00 0 Does not wait for check paper or cleaning sheet to be inserted.
On 08 8 Waits for check paper or cleaning sheet to be inserted.
4 On 10 16 Not used. Fixed to On.
5 Off 00 0 TOF sensor: paper present.
On 20 32 TOF sensor: paper not present.
6 Off 00 0 BOF sensor: paper present.
On 40 64 BOF sensor: paper not present.
7 Off 00 0 Not used. Fixed to Off.
Bit 2: · There may be a time lag between receiving
FS a 0
,
FS c
and selecting the
MICR function.
· Remains 0 (selected) until MICR function is completed.
Bit 3: · Becomes 0 (not waiting) just before starting MICR reading, or starting MICR
head cleaning, after detecting the personal check or cleaning sheet,
respectively.
Bit 5 and 6: · Transmit the current status of the paper sensors.
[Reference]
DLE ENQ
,
FS a 0
,
FS b
,
FS c
, Appendix E
