· The check waiting status continues until: a check is inserted, the waiting state is
cancelled, the waiting time
t1
set by
ESC f
elapses, or the power is turned off.
When check waiting state is cancelled, or when the wait time elapses, the printer
ends reading abnormally. The printer starts reading when a personal check is
inserted.
· When character waveforms or normal waveform reading are not detected or
when an error occurs, the printer ends reading abnormally. Otherwise, the printer
ends reading normally.
· When the printer ends reading abnormally, the printer ejects paper, selects the
default paper type for
ESC c 0
, and ends MICR function. When a recoverable
error occurs, the printer selects the paper roll and ends MICR function when
recovering from the error.
· If the characters read are not identified as the specified character font, the printer
converts the data to “?” .
· When the printer ends reading normally, it transmits “header + reading status
(normal end) + data + NULL” to the host computer. In other cases, it transmits
“header + reading status + NULL” to the host computer.
Header: <5F>H
NUL: <00>H
Each bit of
n
is used as follows:
Bit Off/On Hex Decimal Function
0,1 Readable fonts. See the table below.
2,3 - - - Undefined
4 On 10 16 Rereading not possible. Fixed to On.
5 Off 00 0 Reading normal.
On 20 32 Reading not normal.
6 On 40 64 Not used. Fixed to On.
7 Off 00 0 Not used. Fixed to Off.
Readable Fonts
Hex Decimal Font
00 0 E13B
01 1 CMC7
02 2 Undefined
03 3 Undefined
Bits 0 and 1: Identified character fonts. When bit 5 is 1 (abnormal end), either bit 0 or 1 has no
meaning.
Bit 4: Under the following conditions, the printer sets bit 4=1 (rereading not possible)
À When bit 5=1 (abnormal end),
Á If the MICR status is “ Not Selected”.
 When
ESC @
is executed, the printer is reset, and printer power is on, but the printer
doesn’t execute.
